JM-272S MIG 270 Multi Process Separate
£2,556.96
Price incl.
VAT (20%)
£426.16
Cooling
Please choose
In stock
Product Details
Further reductions on request please contact us via phone or email to discuss.
- Single phase IGBT inverter
- High powered 230V machine
- Digital amp & voltmeter
- 4 roll wire feed unit
- High Duty Cycle
- Advanced control circuitry
- Suitable for 0.6, 0.8, 1.0 and 1.2mm wire
- Burn back control & wire inching
- 2T/4T trigger function
- Power & status LEDs
- Gas check function
- Variable inductance
- Inverter trolley takes full size gas bottle
- MIG/MAG/MMA
Also available as water cooled, select from options above.
Technical Data
| Input voltage | AC 230V - 50/60Hz |
| Ieff | 28.9A |
| Input power | 12.1kVA |
| Voltage adjustment range | 11-29V |
| Current range | 30-270A |
| Duty Cycle @40°c | 270A @ 30% |
| No-load voltage | 54V |
| Wire speed | 0-16m/min |
| Efficiency | 85% |
| Power factor | 0.75 |
| Protection/insulation class | IP21S/F |
| Dimensions (LxWxH) | 1020x505x1460mm |
| Weight | 101kg |
Package includes:
- Inverter power source
- Trolley
- 5m interconnecting cable
- MIG welding torch
- Work return lead and clamp
- Gas hose & regulator
- 5 year warranty (product registration required)
JM-272S MIG 270 Multi Process Separate
